M2A-M21｜Industrial Motherboards｜DFI

M2A-M21
Overview
Overview
Specification
Download
Ordering Information
QUOTE
2
COMPARE
Home Industrial Motherboards Peripherals M2A-M21
  • CHIP: USB3.0 HOST CONTROLLER, UPD720202K8
  • PORT: M.2 A/E Key
  • Support up to 1 M.2 B Key(PCIE/USB3/USB2) (2242) with SIM slot for 4G/5G LTE module, and WIFI module
  • Support up to 2 USB 3 Gen1 / 4 USB2.0 headers
  • DIMENSIONS: 30 x 60 mm (Stand off at 30 x 30 mm)
  • Module Boards

Status : Launched QUOTE NOW

+Compare +Quotation
Product Comparison
You have items. ,Up to 3 items.
COMPARE NOW
Quotation
You have ,Up to 3 items.
QUOTE NOW

M2A-M21 Related Tags

#M.2#SIM Slot
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI
M2A-M21｜Industrial Motherboards｜DFI

Related Products:

Select All - Clear
Specifications
Features
　• CHIP: USB3.0 HOST CONTROLLER, UPD720202K8
　• FEATURES:
　　- Support up to 1 M.2 B Key(PCIE/USB3/USB2) (2242) with SIM slot for 4G/5G LTE module, and WIFI module
　　- Support up to 2 USB 3 Gen1 / 4 USB2.0 headers
　• TEMPERATURE:
　　- Operating: -40°C to 85°C
　　- Storage: -40°C to 85°C
　• HUMIDITY: 5% to 90%
　• DIMENSIONS: 30 x 60 mm (Stand off at 30 x 30 mm)
NOTE: The function depends on the source signal from the motherboard.
Country of Origin
Country of Origin
Taiwan (TAA Compliant Country)
Product Collaterals
Ordering Information
  • Model Name Part Number Description
  • Model Name :
    M2A-M21     Part Number :
     770-M2AM21-000G     Description :
    M.2 A/E key-to-M.2 M/B key(PCIE) (3060,Stdoff-3030) adapter wi SIM slot, 4 USB2.0
  • Model Name :
    M2A-M21     Part Number :
     770-M2AM21-100G     Description :
    M.2 A/E key-to-M.2 M/B key(USB3/2) (3060 Stdoff-3030) adapter wi SIM slot, 4 USB2.0
  • Model Name :
    M2A-M21     Part Number :
     770-M2AM21-200G     Description :
    M.2 A/E key to USB module (3060,Stdoff-3030) with 2 USB3.2 Gen1, 4 USB2.0
  • Model Name :
    M2A-M21     Part Number :
     770-M2AM21-300G     Description :
    M.2 A/E key-to-USB adapter 3060,Stdoff-3030 with 4 USB2.0
