RM645-ICX610
Home Industrial Computers Mini-ITX/ATX System & Chassis RM645-ICX610
  • 4U Short-Depth edge server 3rd Gen Intel® Xeon® processors
  • 3 PCIex16 and  3 PCIe x8 slots support FH/10.5” length cards
  • Up to 8 hot-swappable design available for 2.5” drive bays
  • Rich I/O with 2 GbE, 2 10GbE, 1 RS-232, 4 USB 3.1, 2 USB 2.0
  • IPMI OOB Remote Management
  • Single Display: VGA resolution up to 1920x1200 @ 60Hz
  • 8 288-pin ECC-RDIMM up to 512GB

Status : Preliminary QUOTE NOW

PCIe x16
Windows
Linux
VGA
Multiple Expansion
DDR4
Rich I/O
Product Comparison
You have items. ,Up to 3 items.
COMPARE NOW
Quotation
You have ,Up to 3 items.
QUOTE NOW
CE Certification
FCC Certification

RM645-ICX610 Related Tags

#Windows 10#Edge AI Computing#M.2#3th Gen Intel Xeon Scalable Family#Out-Of-Band (OOB)#IoT#Intel#1G Ethernet#PCIe x16#Windows#Linux#VGA#Multiple Expansion#10G Ethernet#DDR4#CE Certification#FCC Certification
RM645-ICX610|Intel®|Industrial Computers|DFI
RM645-ICX610|Intel®|Industrial Computers|DFI
RM645-ICX610|Intel®|Industrial Computers|DFI
RM645-ICX610|Intel®|Industrial Computers|DFI
System
Processor
3rd Gen Intel® Xeon® Scalable Processor Family, LGA 4189 (Socket P+)
Intel® Xeon® Gold 6338N ( 32 Cores, 48 MB Cache, up to 3.50 GHz )
Intel® Xeon® Gold 6338T ( 24 Cores, 36 MB Cache, up to 3.40 GHz )
Intel® Xeon® Gold 6336Y ( 24 Cores, 36 MB Cache, up to 3.60 GHz )
Intel® Xeon® Gold 6330 ( 28 Cores, 42 MB Cache, up to 3.10 GHz )
Intel® Xeon® Gold 6330N ( 28 Cores, 42 MB Cache, up to 3.40 GHz )
Intel® Xeon® Gold 6326 ( 16 Cores, 24 MB Cache, up to 3.50 GHz )
Intel® Xeon® Gold 6314U ( 32 Cores, 48 MB Cache, up to 3.40 GHz )
Intel® Xeon® Gold 6312U ( 24 Cores, 36 MB Cache, up to 3.60 GHz )
Intel® Xeon® Gold 5320T ( 20 Cores, 30 MB Cache, up to 3.50 GHz )
Intel® Xeon® Gold 5318N ( 24 Cores, 36 MB Cache, up to 3.40 GHz )
Intel® Xeon® Gold 5318Y ( 24 Cores, 36 MB Cache, up to 3.40 GHz )
Intel® Xeon® Gold 5317 ( 12 Cores, 18 MB Cache, up to 3.60 GHz )
Intel® Xeon® Gold 5315Y ( 8 Cores, 12 MB Cache, up to 3.60 GHz )
Intel® Xeon® Silver 4316 ( 20 Cores, 30 MB Cache, up to 3.40 GHz )
Intel® Xeon® Silver 4314 ( 16 Cores, 24 MB Cache, up to 3.40 GHz )
Intel® Xeon® Silver 4310 ( 12 Cores, 18 MB Cache, up to 3.30 GHz )
Intel® Xeon® Silver 4310T ( 10 Cores, 15 MB Cache, up to 3.40 GHz )
Chipset
Intel® C621A Chipset
Memory
8 x 288-pin ECC-RDIMM up to 512GB
Single Channel DDR4 up to 3200 MHZ
BIOS
Insyde SPI 128Mbit
Graphics
Controller
BMC AST2500
Display
1 x VGA (opt.)
resolution up to 1920x1200 @ 60Hz
Storage
External
6 SATA 3.0 (RAID 0/1/5/10)
Internal
1 M.2 2280 M key
Expansion
Interface
3 x PCIe x16 Gen4
3 x PCIe x8 Gen4
Audio
Audio Codec
ALC888S
Interface
Onboard Front Audio Pin Header
Ethernet
Controller
2 Intel® I210
2 Intel® X550-AT2
1 IPMI: RTL8211F
Front I/O
Ethernet
2 x GbE
2 x 10 GbE
1 x Dedicated IPMI LAN (Opt.)
Serial
1 x RS-232 (DB-9)
USB
4 x USB 3.1
2 x USB 2.0
Display
1 x VGA (opt.)
Audio
Onboard Front Audio Pin Header
LED Indicators
1 x Power LED
1 x HDD LED
Button
Buttons
1 x Power Button
Cooling
Fan
12 CM Fan x 2
Watchdog Timer
Output & Interval
System Reset, Programmable via Software from 1 to 255 Seconds
Security
TPM
Infineon TPM2.0 (opt.)
Power
Supply
ATX PS/2 or Mini Redundant PSU
OS Support
Microsoft
Windows 10 IoT Enterprise LTSB RS5(64-bit)
Windows Server 2019
Linux
Ubuntu 20.04
Environment
Operating Temperature
0 to 40°C
Storage Temperature
-30 to 60°C with RTC Battery; -40 to 85°C without RTC Battery
Relative Humidity
5 to 90% RH (non-condensing)
Mechanism
Construction
Heavy Industrial Steel
Mounting
Flexible hold down bar
Dimensions (W x H x D)
481.6 x 175.6 x 470.8mm
Weight
TBD
Color
Black
Standards and Certifications
Shock
Operating: 3G
Non-operating: 5G
Vibration
Operating: random 5~500Hz 1G
Non-operating: sweep sine 10~500Hz 1.5G
Package Drop
ISTA Project 1A
Certifications
CE, FCC class A
Packing List
Packing List
• 1 RM645-ICX610 System Unit
Country of Origin
Country of Origin
Taiwan (TAA Compliant Country)
Ordering Information
  • Model Name Part Number Description
  • Model Name :
    RM645-ICX610
    Part Number :
    TBD
    Description :
    TBD
